Electromagnetic Vibrating Feeder Electromagnetic Vibrating Feeder

Electromagnetic vibrating feeder is an advanced feeder device which is suitable for continuous production. It is widely used in such industrial departments as cement, mining, metal... Bookmark and Share

PDF (124.0KB)Get Quote
Introduction

Electromagnetic vibrating feeder is an advanced feeder device which is suitable for continuous production. It is widely used in such industrial departments as cement, mining, metallurgy, coal yard, chemistry, infrastructure construction, wharf, pharmacy, tea processing and ceramics industry, and in the production process, it is able to quantitatively, evenly and continuously send the non-glutinous particles or powdery materials from the storage bin to the material receiving device.

Electromagnetic Vibrating Feeder

Features

1. There are no rotating spare parts, so there is no need for bearing reduction gear and lubricating grease.

2. It has simple structure, small boundary dimension, light weight and convenient maintenance.

3. The needed driving power is small and the electricity consumption is low. There is no big starting current when the machine is started and the noise is low.

Principle

Electromagnetic vibrating feeder applies the resonance principle of the mechanical vibration, and the two masses work in the low critical and near-resonance state. The materials inside the feeding chute are continuously thrown up in the feeding process and jump forward along the track of parabola.

Technical Data
Item
Model
Feeding capacity
£¨t/h£©
Max.feeding size
(mm)
Power
(w)
Voltage
(v)
Electric current
(a)
Double amplitude
(mm)
Clearance
(mm)
Total weight
(kg)
GZ1
5
50
60
220
1≤
1.75
1.9-2.2
75
GZ2
10
60
150
220
2.3≤
1.75
1.9-2.2
155
GZ3
25
70
200
220
3.8≤
1.75
1.9-2.2
225
GZ4
50
100
450
220
7≤
1.75
1.9-2.2
460
GZ5
100
150
650
220
10.6≤
1.75
1.9-2.2
656
