Roll Crusher Roll Crusher

Roll crusher, which can also be called roller crusher, teeth roller crusher or double roll crusher, is mainly used for the medium crushing and fine crushing of raw materials such a... Bookmark and Share

PDF (94.0KB)Get Quote
Introduction

Roll crusher, which can also be called roller crusher, teeth roller crusher or double roll crusher, is mainly used for the medium crushing and fine crushing of raw materials such as coal, coal gangue, coke, limestone, sulfur ore and phosphate ore. The crushing method of roller crusher is roller extrusion type, and the compression strength of the materials to be crushed should not exceed 80MPa.

Roll Crusher

Features

Roll crusher, which can also be called roller crusher, teeth roller crusher or double roll crusher, is mainly used for the medium crushing and fine crushing of raw materials such as coal, coal gangue, coke, limestone, sulfur ore and phosphate ore. The crushing method of roller crusher is roller extrusion type, and the compression strength of the materials to be crushed should not exceed 80MPa.

Principle

The main working part of double roll crusher is the two rollers parallelly installed on the two horizontal shafts. After the materials that are fed into the crushing chamber are rolled and crushed by the roller, they will go into the material picking hopper through the gap between the two rollers, and adjusting this gap can change the discharging granularity.

Roller crusher can be not only independently used to complete the crushing process, but combined with other crushing machines. Then it is advisable to consider convenience and facilitation. In addition, roller crusher should be installed in a place with good ventilation and with shelters.

Technical Data
Model 2PG0425 2PG0640 2PG0740 2PG0850 2PG1060 2PG1260 2PG1560
Roller diameter(mm) Ф400 Ф610 Ф700 Ф800 Ф1000 Ф1200 Ф1500
Roller width(mm) 250 400 400 500 600 600 600
Input Size(mm) ≤25 ≤25 ≤25 ≤25 ≤30 ≤30 ≤30
Discharging Gate(mm) 2-8 2-8 2-8 2-8 2-10 2-10 2-10
Processing capacity(t/h) 5-10 10-20 15-30 20-40 30-50 40-70 60-110
Power Models Y132M-6 Y180L-6 Y200L-4 Y225M-4 Y250M-4 Y315M-6 Y315L-6
Motor power(kw) 5.5×2 15×2 30×2 45×2 55×2 75×2 110×2
Total weight(t) 2.2 5.9 9.8 13.5 17.2 28.5 39.3
